S-H11R1-WT/2

Racing Line (Titanium) for

Honda CRF1100L Africa Twin 2023

CRF1100L Africa Twin

ADV350 CB1000 HORNET CB1000 HORNET SP CB1000 R CB1100SF (X11)CB1300 CB300R CB400 CB400/500F CB400/500X CB500 HORNET CB500F CB600F HORNET CB600S HORNET CB650F CB650R CB750 HORNET CB900F HORNET CBF1000 CBF600 CBR1000RR CBR1000RR ABS CBR1000RR SP / SP2 CBR1000RR-R FIREBLADE / SP CBR1100XX CBR125 R CBR150 R CBR250 R CBR250RR CBR300R CBR400/500 R CBR600 F CBR600RR CBR650F CBR650R CBR900RR CRF1000L AFRICA TWIN CRF1000L AFRICA TWIN ADVENTURE SPORTS CRF1100L AFRICA TWIN CRF1100L AFRICA TWIN ADVENTURE SPORTS CRF150R CRF250R / 250RX CRF250X / CRE250X CRF300L / RALLY CRF450R / 450RX CRF450R SM CRF450X CRF50F CRF70F GB350S / CB350RS INTEGRA MONKEY MSX125 / GROM NC700 / NC750S NC700/ NC750X NSF250 (MOTO3)NSS125 FORZA NSS250 FORZA NSS300 FORZA NSS350 FORZA NSS750 FORZA NT1100 NX500 PCX125 / PC150 PS125I / PC150I SH125I SH150I SH300I VFR1200F VFR1200X CROSSTOURER VFR800F VFR800X CROSSRUNNER VTR1000F VTR1000SP X-ADV 750 XL1000 VARADERO XL750 TRANSALP XR650R

2023

2026 2025 2024 2023 2022 2021 2020

FIND A RESELLER IN YOUR COUNTRY

Power

+5 kW

at 4200 rpm

Torque

+5.2 Nm

at 7500 rpm

Weight

-5 kg

The Akrapovič Racing system is designed for riders who demand maximum performance. Racing system is lighter if compared to stock exhaust system and features exceptional production quality, hi-tech materials and of course increased engine performance combined with pure racing sound output. The double-flow muffler is a unique combination of a hexagonal shape and a more classic rear endcap, finished with a durable titanium muffler sleeve and robust carbon-fibre clamp.

For perfect performance, throttle response and durability, ECU remapping is recommended.

FITMENT NOTICE: This product is compatible with original Honda center stand, engine guard and pannier stays.

THIS PRODUCT DOES NOT MEET EMISSION COMPLIANCE REQUIREMENTS FOR STREET OR HIGHWAY USE.

OTHER PRODUCTS

EXPERIENCE THE SOUND

VIEW THE DATA

DOWNLOAD DOCUMENTS

Racing Line (Titanium) for Honda CRF1100L Africa Twin 2023

OTHER PRODUCTS FOR HONDA CRF1100L AFRICA TWIN

Honda CRF1100L Africa Twin 2023

Racing Line (Titanium)

S-H11R3-WT

Honda CRF1100L Africa Twin 2023

Slip-On Line (Titanium)

S-H11SO2-HGJT

EXPERIENCE THE SOUND

Immerse yourself in the sound of the Honda CRF1100L Africa Twin exhaust systems.

Stock

Racing line

VIEW THE DATA

	Unit	Akrapovič	Max gain
Max. power	kW	76.5 / 6550 rpm	+ 5 / 4200 rpm
	HP (m)	104 / 6550 rpm	+ 6.8 / 4200 rpm
	HP (i)	102.5 / 6550 rpm	+ 6.7 / 4200 rpm
Max. torque	Nm	101 / 7500 rpm	+ 5.2 / 7500 rpm
	lb-ft	74.5 / 7500 rpm	+ 3.8 / 7500 rpm
Weight	kg	5.24	- 5
	lb	11.6	- 11
	%		- 48.8
Volume	dB	103.1 / 3750 rpm	12
Inst. time	min	60

DOWNLOAD DOCUMENTS

Schematic new version / PDF (1,5Mb)

Installation instructions - EN / PDF (1,5Mb)

Performance graph / PDF (1,5Mb)

Installation instructions - DE, IT, FR, ES, PT, SI / PDF (1,5Mb)
